360_VisionDome_Int_&_Ext_Inst_manual_V2.03_2006-03-14.doc Page 11 of 25
VisionDome Installation Manual
©360 Vision Technology Ltd Version 2.03
Step 4 – Fit locking screw
Once twisted and locked, please insert 1 x M3 CSK screw (provided in fixing pack) and
securely tighten. This will ensure the rigidity as well as the security of the installation.
Step 5 – Attach acrylic
To attach the acrylic, line up the 3 gaps in the rim of the acrylic with the 3 lugs on the
VisionDome. Push and twist clockwise for a clean and easy fit.
Step 6 – Power up
After ensuring all fixings are secure, connect the VisionDome to the supplied PSU, power up
and proceed to programming. (See section 18 - Adjustment of Gain and Lift)
