VisionDome and Vision-i-Dome DATA
20. Technical Information
ViD-18COP04 ViD-22COP04 VDE-18COP01 VDE-18CMP01 VDE-26CMP01
Dome Camera
Sony 18xC
EX45BP
Hitachi 22xC
VKS214ER
Sony18xC
EX48BP
Sony 18xCM
EX480BP
Sony 26xCM
EX980P
Internal Dome Internal Dome External Dome External Dome External Dome
Colour/Mono Colour Colour Colour Colour/Mono Colour/Mono
Zoom (optical) 18x 22x 18x 18x 26x
Zoom (digital) 12x 2x 12x 12x 12x
Total Zoom 216x 44x 216x 216x 312x
Line Resolution 460 460 460 460 460
Pixels 752(H) 582(V) 752(H) 582(V) 752(H) 582(V) 752(H) 582(V) 752(H) 582(V)
Horizontal view
angle
2.7 (T)
48
o
(W)
2.2
o
(T)
47
o
(W)
2.7
o
(T)
48
o
(W)
2.7
o
(T)
48
o
(W)
2.2
o
(T)
54.2
o
(W)
Lens Size 4.1- 73.8 mm 4 - 64 mm 4.1 - 73.8 mm 4.1 - 73.8 mm 3.5 – 91.0 mm
Wide Dynamic
Range
N N N N N
X Wave
Technology
Y N Y Y Y
Steady Shot N N N N N
Min Illumination
colour
1 lux 3 lux 0.7 lux 0.7 lux 1 lux
Min Illumination
colour
Integration
n/a n/a 0.05 lux 0.05 lux 0.07 lux
Min Illumination
mono integration
n/a n/a n/a 0.01 lux 0.01 lux
S/N ratio >50 dB >50 dB >50 dB >50 dB >50 dB
Video Output 1V pk-pk 1V pk-pk 1V pk-pk 1V pk-pk 1V pk-pk
Scanning PAL PAL PAL PAL PAL
Focus/ Iris Auto / manual Auto / manual Auto / manual Auto / manual Auto / manual
Presets 36 36 360 360 360
Menu
Programmable
Tours
2 (max 36
presets per our)
2 (max 36
presets per our)
4 (max 128
presets per tour)
4 (max 128
presets per tour)
4 (max 128
presets per tour)
Address Range Up To 64 Domes Up To 64 Domes
Up to 128
Domes
Up to 128
Domes
Up to 128
Domes
Learned Patrols 2 Mimic Tours 2 Mimic Tours 4 mimic tours 4 mimic tours 4 mimic tours
Remote Reset Yes Yes Yes Yes Yes
Halt During
Initialisation
No
No Yes Yes Yes
Proportional
Speed
Yes Yes Yes Yes Yes
Fast Shutter No No Yes Yes Yes
White Balance
Indoor/Outdoor/
Auto
Yes Yes Yes Yes Yes
OSD in
VisionDome
Yes Yes Yes Yes
Yes
Gain & Lift No No Yes Yes Yes
Auto Homing
Yes (Preset,
Tour or Mimic)
Yes (Preset,
Tour or Mimic)
Yes (Preset,
Tour or Mimic)
Yes (Preset,
Tour or Mimic)
Yes (Preset,
Tour or Mimic)
