ViD-18COP04 ViD-22COP04 VDE-18COP01 VDE-18CMP01 VDE-26CMP01
Freeze Presets No No Yes Yes Yes
Auto Flip Yes Yes Yes Yes Yes
Level adjustment
for colour/mono
change over
No
No No Yes Yes
* Privacy Zones No No
32 with 8 present
on screen
simultaneously
32 with 8 present
on screen
simultaneously
32 with 8 present
on screen
simultaneously
Line Lock Yes Yes Yes Yes Yes
Telemetry
Coax/RS485
(auto select)
(Pelco P,D BR
2400-4800-
9600),
BBV/Dennard
FSK, MM FSK,
Sensornet/AD
Coax/RS485
(auto select)
(Pelco P,D BR
2400-4800-
9600),
BBV/Dennard
FSK, MM FSK
Sensornet/AD
Coax/RS485
(auto select)
(Pelco P,D BR
2400-4800-
9600),
BBV/Dennard
FSK, MM FSK
Sensornet/AD
Coax/RS485
(auto select)
(Pelco P,D BR
2400-4800-
9600),
BBV/Dennard
FSK, MM FSK
Sensornet/AD
Coax/RS485
(auto select)
(Pelco P,D BR
2400-4800-
9600),
BBV/Dennard
FSK, MM FSK
Sensornet/AD
Operating Temp -10
o
C to +50
o
C -10
o
C to +50
o
C -20
o
C to +50
o
C -20
o
C to +50
o
C -20
o
C to +50
o
C
Variable Pan
Speed
0.1 – 400
o
/sec 0.1 – 400
o
/sec 0.1 – 400
o
/sec 0.1 – 400
o
/sec 0.1 – 400
o
/sec
Pan Coverage
360° continuous 360° continuous
360° continuous 360° continuous 360° continuous
Variable Tilt
Speed
0.1 – 200
o
/sec 0.1 – 200
o
/sec 0.1 – 200
o
/sec 0.1 – 200
o
/sec 0.1 – 200
o
/sec
Tilt Movement 90
o
90
o
90
o
90
o
90
o
Power
Internal: 24Vac
36VA 1.5A fuse,
Internal: 24Vac
36VA 1.5A fuse,
External: 24Vac
80VA T2.5A fuse
for VisionDome
+ heater.
External: 24Vac
80VA T2.5A fuse
for VisionDome
+ heater.
External: 24Vac
80VA T2.5A fuse
for VisionDome
+ heater.
Recommended
PSU
VDI-PSU
[1 x 1.5A fuse]
VDI-PSU
[1 x 1.5A fuse]
VDE-PSU
[1 x T2.5A Fuse]
or VDE-
MALARM-EU
(1 x T2.5A Fuse
& 1 x T200Ma
Fuse)
VDE-PSU
[1 x T2.5A Fuse]
or VDE-
MALARM-EU
(1 x T2.5A Fuse
& 1 x T200Ma
Fuse)
VDE-PSU
[1 x T2.5A Fuse]
or VDE-
MALARM-EU
(1 x T2.5A Fuse
& 1 x T200Ma
Fuse)
Mounting
Options
Wall, Ceiling,
False Ceiling
Wall, Ceiling,
False Ceiling
Wall,
Wall-corner,
Pole, Soffit,
Swan neck
Wall,
Wall-corner,
Pole, Soffit,
Swan neck
Wall,
Wall-corner,
Pole, Soffit,
Swan neck
