VisionDome Installation Manual

2. Address Settings for Twisted Pair Installations

When controlling VisionDomes using Twisted Pair RS485, it is necessary to set the address

switches in the VisionDomes. Charts showing the address switch settings for the internal and

external VisionDomes are included with the Quick-Start-Guides.

For VisionDomes use 360-Quick-Start-Guide-VisionDome

For Vision-i-Domes use 360-Quick-Start-Guide-Vision-i-Dome

3. Vision-i-Domes On Screen Menus - advanced features.

Control of the advanced features of the VisionDomes and Vision-i-Domes can be done using

the menus in the VisionMatrix. When using Vision-i-Domes the On Screen Display (OSD)

menus can be used. A description of these menus is included in the

360-Quick-Start-Guide-Vision-i-Dome

Protocol Selection

Several different protocols can be used to control the VisionDomes. As the VisionDomes and

Vision-i-Domes have different features, the DIL switches MUST be set as described in the

appropriate Quick-Start Guides.

For VisionDomes use 360-Quick-Start-Guide-VisionDome

For Vision-i-Domes use 360-Quick-Start-Guide-Vision-i-Dome
