1-11

[Sysname] interface Ethernet1/0/3

[Sysname-Ethernet1/0/3] lacp enable

The three LACP-enabled ports can be aggregated into one dynamic aggregation group to implement

load sharing only when they have the same basic configuration (such as rate, duplex mode, and so on).
