1-13
System View: return to User View with Ctrl+Z.
[Sysname] interface Vlan-interface 1
[Sysname-Vlan-interface1] ip address 192.168.0.28 255.255.255.0
Step 3: Enable FTP service on the switch, and configure the FTP user name to test and password to
pass.
[Sysname-Vlan-interface1] quit
[Sysname] ftp server enable
[Sysname] local-user test
New local user added.
[Sysname-luser-test] password simple pass
[Sysname-luser-test] service-type ftp
Step 4: Enable FTP client software on the PC. Refer to Figure 1-10 for the command line interface in
Windows operating system.
Figure 1-10 Command line interface
Step 5: Use the cd command on the interface to enter the path that the Boot ROM upgrade file is to be
stored. Assume the name of the path is D:\Bootrom, as shown in
Figure 1-11.
