3Com Baseline Switch 2900 Series User Manual

5-8
Figure 5-4 Reestablish the connection
The new settings can take effect only after you reestablish the connection.
6) Establish a connection between the terminal and the switch using the changed rate
Press Enter to reestablish the connection between the terminal and the switch and download the
application file at 115200 bps. The following information is displayed:
Now please start transfer file with XMODEM protocol
If you want to exit, Press <Ctrl+X>
Loading ...CCCCCCCCCCCCC
Press Ctrl + X to quit downloading files; otherwise, proceed as follows.
7) Uploading an application file from the terminal to the switch
Step1 Select Transfer > Send File in the HyperTerminal window (as shown in
Figure 5-5). Click Browse in
the pop-up dialog box (as shown in
Figure 5-6) to select the application file to be downloaded (for
example, update.bin), and select Xmodem from the Protocol drop-down list.
Figure 5-5 Transfer menu
