Inserting the NIC 21
Figure 2 Installing the NIC
7 Secure the NIC with the screw you removed in step 5.
If you want to install the Remote Wake-Up cable, go to the
next section, “Connecting the Remote Wake-Up Cable” to
continue the installation. If you want to connect a cable from
the SOS or SMBus connector, see your PC documentation or
contact your PC manufacturer for instructions.
If you do not want to connect a cable, continue with step 8.
8 Replace the PC cover and plug in the power cord.
Do not turn on the power to the PC.
9 Go to “Connecting to the Network” later in this chapter.
1 Remove slot cover
2 Insert NIC
PCI slots
book Page 21 Monday, March 15, 1999 1:31 PM
