A
SPECIFICATIONS AND
CABLING REQUIREMENTS
This appendix lists the specifications, standards
conformance, cable requirements, and connector pin
assignments for the 3C905C NIC.
Hardware Specifications
Network Interface
Physical Dimensions
Environmental Operating Range
Power Requirements
10 Mbps Ethernet
10BASE-T
Ethernet IEEE 802.3 industry standard for
a 10 Mbps baseband CSMA/CD local
area network
100 Mbps Fast Ethernet
100BASE-TX
Fast Ethernet IEEE 802.3u industry standard
for a 100 Mbps baseband CSMA/CD local
area network
Length: 14.86 cm (5.85 in)
Width: 7.62 cm (3.00 in)
Operating temperature: 0º to 70º C (32º to 158º F)
Humidity: 10 to 90% noncondensing
Altitude -300 to 3,000 meters (-984 to 9,840 ft)
Operating voltage: +3.3 V ± 5% @ 375 mA max
