TECHNICAL SPECIFICATIONS
Switch 4500 (26 Port)
Physical Dimensions Height: 44 mm (1.7 in.) x Width: 440 mm (17.3 in.) x Depth: 274 mm (10.8 in.)
Weight: 4.4kg (9.72 Ibs)
Environmental Requirements
Operating Temperature 0 ° to 40 °C (32 ° to 104 °F)
Storage Temperature –10 ° to +70 °C (14 ° to 158 °F)
Operating Humidity 95% non-condensing
Standards EN60068 to 3Com schedule (Package testing: paras 2.1, 2.2, 2.30, and 2.32.
Operational testing: paras 2.1, 2.2, 2.30 and 2.13).
Safety
Agency Certifications UL 60950, EN60950, CSA 22.2 No. 60950, IEC 60950
EMC
Emissions CISPRR 22 Class A, EN55022 Class A, FCC Part 15 Subpart B Class A,
ICES-003 Class A, EN61000-3-2, EN61000-3-3
Immunity EN 55024
Power Consumption 35 watts maximum
Heat Dissipation 120 BTU/hour maximum
Power Supply
AC
Line Frequency 50/60Hz
Input Voltage 100-240 VAC
Current Rating 1.0A (amps) maximum
