vii
F
IGURES
1-1
3C905B-TX NIC 1-1
1-2
3C905B-TX NIC Installation Steps 1-4
2-1
Inserting the NIC 2-2
2-2
Connecting the Network Cable to the RJ-45 Port 2-3
2-3
Connecting the NIC to the Connector 2-4
4-1
LEDs 4-2
4-2
3Com NIC Diagnostics Program General Screen 4-4
4-3
Diagnostics Screen 4-5
4-4
3Com NIC Diagnostics Program Support Screen 4-7
4-5
Problem Report Main Screen 4-9
4-6
Computer Information Screen 4-9
4-7
Straight-through and Crossover Cable Pinouts 4-13
5-1
3Com NIC Diagnostics Program General Screen 5-3
5-2
3Com NIC Diagnostics Properties Screen 5-3
A-1
RJ-45 Connector Pin Assignments A-2
