Care & Maintenance
Maintenance
For the safety of the user and to avoid shock or unintended
motion, all maintenance of the 3DP Workbench printer
should be:
• Conducted with the machine unplugged from all
electrical outlets.
• Conducted when the machine is cool.
Exception: maintenance and replacement of the extruder
nozzles must be done when the extruder is heated.
Use extreme caution when maintaining or operating
heated machinery. See details—Cleaning the Nozzle and
Changing the Nozzle—on page 19.
For the safety of the user, use extreme caution
when working with heated machinery.
SIMO® Series actuators from PBC Linear®:
• Rail and bearing system is inclusive of internal
lubrication system—requiring no preventative
maintenance—for the lifetime of the machine.
• Teflon coated screw, with engineered polymer nut
is designed for lifetime operation under normal
operating conditions—see Work Environment
on page 10.
• Cam Roller carriages include built-in micro-polymer
lubricators. If lubricators become damaged, contact
manufacturer for replacement.
Motor LED Error Codes
The TSM23P uses red and green LEDs to indicate status.
When the motor is enabled, the green LED flashes slowly.
When the green LED is solid, the motor is disabled. Errors
are indicated by combinations of red and green flashes as
shown below.
CODE ERROR
●
solid green motor disabled
● ●
flashing green motor enabled
● ●
1 red, 1 green position limit
● ● ●
1 red, 2 green drive disabled
● ● ●
2 red, 1 green ccw limit
● ● ● ●
2 red, 2 green cw limit
● ● ● ●
3 red, 1 green over temperature
● ● ● ● ●
3 red, 2 green internal voltage
● ● ● ● ● ●
3 red, 3 green
non-volatile memory
error
● ● ● ● ●
4 red, 1 green over voltage
● ● ● ● ● ●
4 red, 2 green under voltage
● ● ● ● ● ● ●
4 red, 3 green
non-volatile double
error
● ● ● ● ● ●
5 red, 1 green over current
● ● ● ● ● ● ●
5 red, 2 green current limit
● ● ● ● ● ● ●
6 red, 1 green open winding
● ● ● ● ● ● ● ●
6 red, 2 green encoder failure
● ● ● ● ● ● ● ●
7 red, 1 green communication error
● ● ● ● ● ● ● ● ●
7 red, 2 green save failed
