Illustrated Parts Breakdown3MtOverhead Projector 9000 Series
i
E 3M 2000
Revision History
Revision bars placed in the margins ( ) indicate where additions or changes to a parts identification list
occurred. Items deleted from a parts identification list are indicated on the next 3 pages only. Changes to
illustrations are not indicated by revision bars, nor shown in this revision history.
The original issue of this manual and subsequent revisions are identified as follows:
Issue date: 4/94
Revision Date Page(s) Changed Change
Original April 1994 All pages
August 1994 All pages
July 1995 All pages
July 1996 All pages
January 1998 All pages
August 1998 All pages
June 1999 (Rev G) Europe Only
April 2000 (Rev H) All Areas
All Rev G changed pages are documenting the
addition of the 9400 within the 9000 Series IPB.
Page 3 Changed the Fan Blade from 78-8079-8788-4 to
78-8054-1823-9. Changed the Diode
78-8064-1834-5 to Diode Kit 78-8054-1836-1.
Added new Fan Motor Assembly (International)
(78-8054-1855-1), and Fan Motor Assembly
(U.S.) (78-8114-9015-6). Changed Fan Motor
120V from 78-8079-8787-6 to 78-8120-2914-4,
and Fan Motor 230V from 78-8079-8936-9 to
78-8120-2917-7.
Page 9 Changed quantity of item 9 from 2 to 3.
Page 11 Added item 0C, Triplet Head Assembly,
and item 3B, 317mm Triplet Lens
(78-8014-8916-8). Added the 9400 to the
listings for items 8A and 12B.
Page 12 Added the 9400 to the listing of “Detail A” in
the Arm and Focus Assembly art. Added item
22 to “Detail B” art.
Page 13 Changed item 0A from 78-8073-2951-1 to
DY-0210-2704-9, Focus Arm Kit for Europe.
To Next Page
