IllustratedPartsBreakdown3MtOverheadProjector9000Series
7--1
E3M2000
TableofContents
SectionNo. Title Page
QuickReferencePartsIndex 3.............. .................................................
0 Overview 5............ ................................................................
1 WideAngle(Open)293mmHeadAssembly 6............ ....................................
2 Articulate(Closed)HeadAssemblies 8............ ..........................................
3 TripletandVarifocal(Open)HeadAssemblies 10............ ..................................
4 ArmandFocusAssembly 12............ ..................................................
5 TopCover 14............ ..............................................................
6 BaseEnclosure 18............ ..........................................................
7 CoolingFan 22............ .............................................................
8 LampHousing--ENXSingleLamp 26............ ..........................................
9 LampHousing--ENX/FXLDualLamp 28............ .......................................
10A LampHousing--EVDDualLamp-9550(MfgCodeA3andearlier) 30.......... ...............
10B LampHousing--EVDDualLamp-9550(MfgCodeA3andlater) 32.......... .................
11 LampHousing--FNTSingleLamp 34 ........... ..........................................
12A LampHousing--FNTDualLamp(MfgCodeA3andearlier) 36.......... .....................
12B LampHousing--FNTDualLamp(MfgCodeA3andlater) 38.......... .......................
13 LampchangerandHi/LoLampControlModule(DualLampversions) 40........... ..............
14 RollerAssembly 44........... .........................................................
15 WireJumpers 46........... ............................................................
AppendixA Specifications 51... ...........................................................
IMPORTANTNOTICE
3MreservestherighttosellorfurnishNEWORRECONDITIONEDPARTS.
Newandreconditionedpartsarecoveredbythesame3Mnewpartslimitedwarranty.
