© 3M 2008. All Rights Reserved. 45
3M™ Digital Projector DX70i Appendices
READ from projector
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-
232 ASCII Code HEX Code Function Projector Return Description
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
-
IDnnIR098 49 44 30 30 49 52 30 39 38 Information OKabbbbcdddde a : 1/0=on/off
bbbb: LampHour
c: source 0/1/2/3/4/5= none/dvi/vga1/vga2/s-video/video
dddd: FW version
e : display mode
IDnnIR099 49 44 30 30 49 52 30 39 39 Info. to web only OK[data] ( !!! Caution !!! data[ ] are all ASIC character.)
data[0] : 1/0=on/off
data[1..4] : LampHour XXXX
data[5] : source 0/1/2/3/4/5= none/dvi/vga1/vga2/s-video/video
data[6..9] : FW version
data[10] : display format 0/1/2/3=4:3/16:9/window/native
data[11] : display mode 0/1/2/3/4=PC/Photo/Video/sRGB/User
data[12..13] : volume XX
data[14..16] : brightness XXX
data[17..19] : contrast XXX
data[20..22] : colour XXX
data[23] : AV mute 1/0=on/off
data[24] : Freeze 1/0=on/off
data[25] : Lamp lite 1/0= ok/failed.
data[26] : (bright mode) Economic mode 0/1= off/on.
data[27] : (screen) pip 0/1=disable/enable
data[28] : pip location 0/1/2/3/4=left-top/right-top/center/left-bottom/right-bottom
data[29] : colour temperature 0/1/2/3/4=low/med/high/sRGB/user
data[30] : projection 0/1/2/3=front/front-ceiling/rear/rear-ceiling.
data[31] : digamma X
data[32..33] : language XX
0=English 1=Français 2=Deutsch
3=Italiano 4=Español 5=Português
6=Svenska 7=Nederlands 8=Finnish
9=Greek 10=Danish 11=Norsk
12=Polski 13=Ɋɭɫɫɤɢɣ 14=亞󰪠խ֮
15=᜗᧯խ֮ 16=ֲء፿ 17=䞲ῃ㠊
data[34..35] : sharpness XX
data[36..37] : tracking XX
data[38..39] : white peaking XX
data[40..41] : (zoom value) zoom XX
data[42..43] : vertical shift XX
data[44..46] : vertical position XXX
data[47..49] : horizontal position XXX
data[50..52] : vertical keystone XXX
data[53..55] : horizontal keystone XXX
data[56..58] : (auto shutdown) auto power off XXX
