3M DX70i - Product Overview; Main Unit

6 © 3M 2008. All Rights Reserved.
Introduction 3M™ Digital Projector
1. Control Panel
2. Zoom Lever
3. Focus Ring
4. Elevator Button (one on each side)
5. Elevator Foot (one on each side)
6. Zoom Lens
7. IR Receivers
8. Power Socket
9. Connection Ports
Main Unit
Product Overview
