ABOUT THIS MANUAL
There are two basic models included in the 3M
™
Dynatel
™
Locator
2200M Series. The 2250M locator is designed for cable/pipe locating.
The 2273M unit is designed for cable/pipe and fault locating. The iD
option (read/write capability to 3M
™
iD Markers 1400 Series) is available
for both models. This instruction manual will include all features. All
instructions are applicable to both products, unless noted.
In order to demonstrate all available functions, the illustrations depict the
2273M-iD unit. The 2250M-iD locator may vary from the illustrations
shown.
QUICK START
Battery Installation
Transmitter
Press and hold OFF [T-1] to manually test the batteries. The display and
audio will indicate one of the following levels: (OK w/solid tone = good;
LO w/beeping tone = low; “--” w/no tone = replace)
Receiver
4
6 'C'
cells
8 'AA'
cells
