5454
Frequencies
Trace Mode 577 Hz
8 KHz
33 KHz
200 KHz
Fault Mode 10/20 Hz - fault
577 Hz / 33 KHz - trace
Tone Mode 577 Hz and 200 Hz @ 8 Hz
Induction Mode 33 KHz and 200 KHz
Output Power 3 Watt maximum
5 Watt w/external DC source
Weight w/batteries 5.2 lbs (2.4 kg)
Battery Qty. and size 6 "C"
Battery Life 50 hours (Normal output level)
10 hours (High output level)
Rechargeable battery will extend
operation time by 20%
External DC Power 9–18 V DC
Transmitter Specs 3M
™
Dynatel
™
Locators 2250M and 2273M
This is the EU symbol for equipment that is
covered under the Waste from Electrical and
Electronic Equipment (WEEE) directive per
CENELEC Specification 50419, and it indicates
that certain products should not be discarded in the
trash, but rather should be recycled. This applies
to all electronic pluggable and battery powered
products.
