SECTION 12
Specifications for North America Power Supply
SECTION 13
Parts Included
1 ea. Workstation Monitor 724
1 ea. Dual Conductor Remote Input Jack 732
1 ea. AC Adapter (North America Power Supply).
For EU/EK Power Supply, place separate
order, 80-0014-0111-8.
1 ea. 3M
™
Ground Cord
1 ea. 3M
™
Monitor/Table Mat Cord 2380D
1 ea. Two-Wire Connector
4 ea. Mounting Screws
2 ea. Wire Management Clips
1 ea. User’s Guide
3M
™
Workstation Monitor
724 Dimensions
6.5 x 3.125 x 1.375 in. (16.5 x 7.9 x 3.5 cm)
3M
™
Dual Conductor Remote Input
Jack 732 and 733 Dimensions
2.75 x 1.0 x 1.0 in. (7.0 x 2.5 x 2.5 cm)
Power Supply Requirements
(North America version, included;
EU/EK version, optional)
Input: 100-200VAC +/-10% Output: 25VDC @ 50 mA rated load
Output Plug Polarization Center Negative
Output Plug Dimensions 5.5 mm O.D. x 2.1 mm I.D. x 9.5 mm Length
Test Voltage 9 VDC / 16 VDC Open circuit (Typical Value)
Test Current Less than 3 microamps (Typical Value)
Environmental Operating Conditions Indoor use only
Temperature Maximum: 110°F / 43°C Minimum: 50°F / 10°C
Humidity Maximum relative humidity 80% for temperatures up to 31°C to
50% relative humidity at 40°C.
