3MillID S-Gang Keypad Reader - MIFARE, ENDIAN, and DESFire Configuration

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
+1 303 475 4972
sales@3millid.com
© 3millID
100-02640-A
www.3millid.com
MANUAL
3M
S-Gang
Keypad
11
RX80 MIFARE
PIN CODES
*20
set reader to read ‘MIFARE®’
RX80 ENDIAN
PIN CODES
*21
set reader to read ‘ENDIAN’
RX90 DESFire
PIN CODES
*30
set reader to read ‘DESFire®’
*20n#
example
*200#
*201#
*202#
*203#
*204#
*205#
.....
.....
.....
.....
.....
.....
*21n#
example
*210#
*211#
.....
.....
*30n#
example
*300#
*301#
.....
.....
The following instructions give a step-by-step procedure for accessing the many features
supported by this reader.
4.keypad programming guide
To set 26-bit Wiegand enter: *201# once the reader has
been placed into programming mode.
Configure reader to read ‘MIFARE®’ proximity cards.
6
8
0
9
#
4
7
*
5
123
DISABLE function
26-bit WIEGAND
32-bit WIEGAND
34-bit WIEGAND
Clock and Data
MIFARE® SE
To set Little ENDIAN enter: *211# once the reader has
been placed into programming mode.
Configure reader to read ‘ENDIAN’ proximity cards.
6
8
0
9
#
4
7
*
5
123
Big ENDIAN
Little ENDIAN
To ENABLE function, enter: *301# once the reader has
been placed into programming mode.
Configure reader to read ‘DESFire®’ proximity cards.
6
8
0
9
#
4
7
*
5
123
DISABLE function
ENABLE function
