MANUAL
3M
S-Gang
Keypad
9
*10n#
example
*100#
*101#
*102#
.....
.....
.....
*11n#
example
*110#
*111#
*112#
*113#
*114#
.....
.....
.....
.....
.....
*12n#
example
*120#
*121#
*122#
*123#
*124#
.....
.....
.....
.....
.....
RX00 HID
PIN CODES
*10
set reader to read ‘HID®’
RX00 EM
PIN CODES
*11
set reader to read ‘EM’
RX00 CASI
PIN CODES
*12
set reader to read ‘CASI’
The following instructions give a step-by-step procedure for accessing the many features
supported by this reader.
4.keypad programming guide
To set WIEGAND Pass Through enter: *101# once the
reader has been placed into programming mode.
Configure reader to read ‘HID®’ proximity cards.
6
8
0
9
#
4
7
*
5
123
DISABLE function
WIEGAND Pass Through
Clock and Data
To set 26-bit WIEGAND enter: *111# once the reader has
been placed into programming mode.
Configure reader to read ‘EM’ proximity cards.
6
8
0
9
#
4
7
*
5
123
DISABLE function
26-bit WIEGAND
34-bit WIEGAND
42-bit WIEGAND
Clock and Data
To set 4001 40-bit WIEGAND enter: *121# once the
reader has been placed into programming mode.
Configure reader to read ‘CASI’ proximity cards.
6
8
0
9
#
4
7
*
5
123
DISABLE function
4001 40-bit WIEGAND
4002 40-bit WIEGAND
Extended 4001 40-bit WIEGAND
Extended 4002 40-bit WIEGAND
