Page 66

4.4.4-6 Gas Pedal Min

Under Gas Pedal Min, minimum value of gas pedal range will be detected automatically and shown here.

4.4.4-7 Gas Pedal Max

Under Gas Pedal Max, maximum value of gas pedal range will be detected automatically and shown here.
