Page 84
4.4.5-11 Fan Test
Under Fan Test, fan (two sides of steering wheel) of the cabinet will be tested here.
Fan Test
Description
Off
Fan is turned off
On
Fan is on for testing
4.4.5-12 Boost Magnet Test
Under Boost Magnet Test, magnet (BOOST Bar) of the cabinet will be tested here.
Note: Turn “ON” and push the boost handle up to ensure it is held in position by the electromagnet.
Boost Magnet
Test
Description
Instruction
Off
Boost Magnet is turned off
Push the boost handle to the top position and release, the
boost handle will automatically drop to the lowest position.
On
Boost Magnet is on for testing
Push the boost handle to the top position and then release it,
the boost handle will be attracted to the top position.
