Cabinet ID White
The cabinet id LED will be white and others will be off
Seat Back Red
The seat back LED will be red and others will be off
Seat Back Green
The seat back LED will be green and others will be off
Seat Back Blue
The seat back LED will be blue and others will be off
Seat Back White
The seat back LED will be white and others will be off
4.4.5-15 SLED1 Board
Under SLED1 Board, status of SLED1 board will be detected and shown here.
SLED1 Board
Description
Connected
SLED1 board is detected and connected
Not Connected
No SLED1 board is detected and connected
