3xLogic VISIX Gen III Series Menu Guide

Pg. 8
Exposure Settings
3
DRC (DYNAMIC RANGE COMPRESSOR)
DRC enables dark areas in images to become more visible without overexposing the bright
areas to create one perfect image. Select from : OFF / LOW / MIDDLE / HIGH
4
DEFOG
Allows the camera to process a scene that is obscured by fog or weather conditions and
provides a visibly improved image. AUTO / MANUAL : Select AUTO to have the WDR and DRC
levels adjusted automatically. Set the DEFOG level from LOW / MIDDLE / HIGH.
5
AGC (AUTO GAIN CONTROL)
0~10 - AGC enhances the picture brightness in low light conditions. A higher level AGC setting
makes the images brighter, however, it could increase the amount of noise.
6
SENS-UP
OFF / x2 ~ x32(Default : X4) - Automatically activates slow shutter function when the image
is too dark. High values are not recommended as they may causes the image to lag.
Sens-up menu cannot be controlled if the SHUTTER setting is above 1/30.
7
3D DNR (3D DIGITAL NOISE REDUCTION)
OFF/LOW/MIDDLE/HIGH - 3D-DNR reduces the noise on the screen in low light conditions
and allows for clearer images, even at night.
DEFOG
MODE
LEVEL
RETURN
AUTO
MIDDLE
EXPOSURE
LENS
BACKLIGHT
DRC
DEFOG
AGC
SENS-UP
3D DNR
EXIT JUMP
AUTO
OFF
____
ON
10
X4
HIGH
3
6
5
4
7
EXPO MOTI PRIVRGB D&N FUNC SET EXIT
