DIGITAL VIDEO RECORDER MANUAL

DIGITAL VIDEO RECODER MANUAL

9 — Event Setup

It is for sensor setup.

[1] Sensor Input : Select the sensor input channel.

[2] On/Off : Select the sensor usage.

[3] Input Type: Select the sensor input type.

• N/Open (NORMAL OPEN) : The contact is normally opened but closed when the signal is

generated.

• N/Close (NORMAL CLOSE) : The contact is normally closed but opend when the signal is

generated.

[4] Related camera: Select the camera to be related with sensor. Multi-selection is possible.

It is the motion detection setup menu.

Motion Detection

Sensor
