7 Water heater
7.1 Structure of the water heater
The water heater has the following main components:
Tank (1) The water is stored and heated up in the tank.
Heating elements (4) The water is heated by the heating elements.
Fig. Components water heater
1. Tank
2. Main Safety thermostat
3. Row Control Thermostat
4. Heating Elements
5. Terminal Block
6. Anodes
0313851_DRE_NLUKFR, 30-03-2022 33
