A.O. Smith T-KJr2-OS User Manual

110 Indoor / 110 Outdoor Service Manual
Ver. 1.01
4
CONFIDENTIA
L
13-3/4" (350mm)
10" (254mm)
2-1/4" (56mm)
21-3/8" (544mm) 20-1/4" (520mm)
2-1/4" (56 mm) COLD
3-7/8" (98mm) GAS
4-7/8" (124mm) HOT
1" (26mm)
4" (102mm)
4-7/8" (123mm) 120 VAC
7-3/4" (196mm)
1-3/4" (45mm)1-3/4" (45mm)
1-7/8" (47mm)
COLD 3-1/8" (79mm)
HOT 5-1/4" (133mm)
120 VAC 1-3/8" (36mm)
GAS 4-7/8" (124mm)
2-1/4" (57mm)
13-1/8" (334mm)
6-1/4" (160mm)
1" (102mm)
COLD 2-1/4" (56mm)
HOT 4-7/8" (124mm)
HOT 5-1/4" (133mm) GAS 4-7/8" (124mm)
120 VAC 1-3/8" (36mm)
GAS 3-7/8" (98mm)
120VAC 4-7/8" (123mm)
COLD 3-1/8" (79mm)
2. Exterior view
110 Indoor
Side view
Front view
Top view
Bottom view
