Chapter 2 Installation 11
Connectors
Label Function
CN1 CPU fan power connector
CN2 PC/104 connector
CN3 USB ports connector
CN5 IDE drive connector
CN6 Front panel connector
CN7 IrDA connector
CN8 ATX power connector
CN9 LCD display connector
CN10 CD-ROM signal input connector
CN11 Keyboard and PS/2 mouse connector
CN12 VGA display connector
CN13 Audio connector
CN14 Printer port connector
CN15 100Base-Tx Ethernet connector
CN16 Serial ports connector
CN17 Floppy dirve connector
LED1 Ethernet Tx/Rx/Link LED connector
U23 DiskOnChip socket
