42 PCM-5896 User Manual
Ethernet LED signal connectors
(LED1)
The PCM-5896 supports three sets of LED connector for external
LED indicators.
Ethernet active signal LED
Flashing Tx or Rx LEDs indicate that the PCM-5896 is transmitting
or receiving data.
Ethernet link signal LED
A continuously lit LED indicates good linkage between the
PCM-5896 and its supporting hub.
Ethernet LED signal connectors (LED1)
Pin Signal
1 Rx LED
2 +5V
3 Link LED
4 +5V
5 Tx LED
6 +5V
