Aaeon PCM-5896 - 100 Base-Tx Ehternet Connector (CN15)

38 PCM-5896 User Manual
100Base-Tx Ethernet connector
(CN15)
This 100Base-Tx Ethernet connector is a standard RJ-45 connec-
tor.
The onboard Realtek RTL8139A fast Ethernet controller supports
10Mb/s and 100 Mb/s N-way auto-negotiation operation.
100Base-Tx Ethernet connector (CN15)
Pin Signal Pin Signal
1 Tx+ 2 Tx-
3 Rx+ 4 N/C
5 N/C 6 Rx-
7 N/C 8 N/C
