32 PCM-5896 User Manual
IrDA connector (CN7)
The IrDA connector (CN7) can be configured to support wireless
infrared module, with this module and application software such as
laplink or Win95 Direct Cable connection, user can transfer files to
or from laptops, notebooks, PDA and printers. This connector
supports HPSIR (115.2Kbps, 2 meters), ASK-IR (56Kbps) and Fast
IR (4Mbps, 2 meters).
Install infrared module onto IrDA connector and enable infrared
function from BIOS setup. Make sure to have correct orientation
when you plug onto IrDA connector.
IrDa connector (CN7)
Pin Signal
1 Vcc
2 FIrRx
3 IrRx
4 GND
5 IrTx
