English 4
Symbols
Symbols Function / Meaning Recommended Action
Standby and Turn the device on.
Battery installation guide
Direct current
SN Serial number
Date of manufacture
Type BF: Device, cuff and tubing are
designed to provide special protection
against electrical shocks.
The indicator that appears while
measurement is in progress. It blinks
when the pulse is detected.
Measurement is in
progress. Remain as
still as possible.
Irregular Heartbeat indicator. (I.H.B.)
The indicator that appears when an irregular
heartbeat or any excessive body movement
is detected during the measurement.
Previous measurements stored in MEMORY.
Full Battery
The battery power indicator during
measurement.
Low Battery
The battery power is low when it blinks.
Replace all batteries
with new ones, when
the indicator blinks.
Unstable blood pressure due to
movement during the measurement.
Try measurement again.
Remain very still during
the measurement.
The systolic and diastolic values are
within 10 mmHg of each other.
The pressure value did not increase
during inflation.
The cuff is not applied correctly.
PUL. DISPLAY ERROR
The pulse is not detected correctly.
Apply the cuff correctly,
and try the
measurement again.
SYS Systolic blood pressure in mmHg
DIA Diastolic blood pressure in mmHg
PUL./min Pulse per minute
EC directive medical device label
WEEE label
Manufacturer
REPEC
EU-representative
Refer to instruction manual/booklet
Class II device
Polarity of DC jack
