AAON Airflow - 5.1.1. MAC Address (BACnet Communication Option); 5.1.2. Instance Number (BACnet Communication Option); 5.1.3. Modbus ID (Modbus Communication Option)

14
5.1.1. MAC Address (BACnet Communication Option)
When the BACnet Communication option is ordered, the MAC Address Menu allows the user to set a
unique device address when connecting to a BACnet network. The default is 002. For additional
information refer to the AAON Outdoor Airflow Measurement System O&M.
Tech. Config.
Password: 1000

4PT Flow Corr
MAC Address
MAC Address

(Range = 02 to 254)
Instance Number
Modbus ID
(002)
5.1.2. Instance Number (BACnet Communication Option)
When the BACnet Communication option is ordered, the Instance Number Menu allows the user to set a
unique device address when connecting to a BACnet network. The default is 1002. For additional
information refer to the AAON Outdoor Airflow Measurement System O&M.
Tech. Config.
Password: 1000

4PT Flow Corr
Instance Number
MAC Address
(Default = 1002)
Instance Number

Modbus ID
(01002)
5.1.3. Modbus ID (Modbus Communication Option)
When the Modbus Communication option is ordered, the Modbus ID Menu allows the user to set a
unique device address when connecting to a Modbus network. The default is 002. For communication
with WattMaster Controls the Modbus ID has been set by the factory to 009 for outside airflow
applications. For additional information refer to the AAON Outdoor Airflow Measurement System
O&M.
Tech. Config.
Password: 1000

4PT Flow Corr
Modbus ID
MAC Address
(Range = 01 to 254)
Instance Number
Modbus ID

(002)
