6.2.3.4. Fixed Value
The Fixed Value Menu allows the user to enter a temperature value for the flow calculations. This value
will not be displayed on the LCD screen.
Field Setup
Menu

Flow Correction
Temperature Units
Fixed Value
AutoZero
Temperature Values
(˚F)
Temp Comp.

Temperature Input
Display Filter
Fixed Value

(+068)
6.3. INPUT/OUTPUT SET-UP
If input or output configuration changes are required refer to the tables in the sections below and the
Figure 1 in Section 3.
6.3.1. Process Output
If controls are provided, the process output has been set by the factory for input to the specific
controller; otherwise the default is 0-10VDC. To change the output configuration, set the S2 & S4
switches as follows:
Process Output
Range
S2
S4
Current
4-20mA
NA
mA
Voltage
0-10VDC
10V
V
Voltage
0-5VDC
5V
V
6.3.2. Temperature Input
Since the AAON Temperature Transmitter has been provided, the temperature input has been set by the
factory for 4-20mA. To change the input configuration, set the S1 switch as follows:
Temperature Input
S1 Switch Selection
4-20mA
mA
0-10VDC
V
