5.2.1.1. Alarm Status
The Alarm Status allows the user to independently turn each alarm ON or OFF.
Field Setup
Menu

Output Filter
Alarm Status

Low Alarm
Alarm Options

Alarm Value
(On)
Factory Defaults
Alarm Delay
High Alarm
Output Filter
(On)
5.2.1.2. Alarm Values
The Alarm Value Menu allows the user to enter the Low or the High flow alarm value. Alarm values
will be displayed in the same engineering units selected in the Engineering Units Menu (see Section
6.2.2).
- High Alarm Function: The High Alarm activates if the flow exceeds the High Alarm value
and resets when the flow drops below the High Alarm Value.
- Low Alarm Function: The Low Alarm activates if the flow drops below the Low Alarm
Value and resets when the flow exceeds the Low Alarm Value.
Field Setup
Menu

Output Filter
Alarm Status
Lo Alarm Value
Alarm Options

Alarm Value

(000,000)
Factory Defaults
Alarm Delay
Hi Alarm Value
Output Filter
(100,000)
5.2.1.3. Alarm Delay
The Alarm Delay Menu allows the user to enter an alarm delay of 0 to 999 seconds before an alarm will
be activated. The alarm will be reset without a delay.
Field Setup
Menu

Output Filter
Alarm Status
Lo Alarm Delay
Alarm Options

Alarm Value
(000)Seconds
Factory Defaults
Alarm Delay

Hi Alarm Delay
(000)Seconds
