1SYSTEM FEATURES AND CONTROLS
Front View 12
Rear View 13
Battery Side 14
Motor Side 15
LCD Control Panel - Quick Reference 16
2 THE CAMERA BODY
2.1 Lenses 20
ArriPL Lens Port 20
Installing the Lens 20
Aaton Lens Port 21
2.2 Viewing System 21
Viewfinder Options 21
Attaching the Extension Finder 22
Viewfinder Tension Adjustments 22
Adjusting the Diopter 23
The Eyepiece Shutter 24
Adjusting the Viewing Horizon 24
Viewing Screen 24
Changing the Viewing Screen 25
Adujsting the Viewing Screen 26
Aatonite Illumination 27
2.3 Mirror Shutter 27
Concept 27
Adjusting the Shutter 28
2.4 Film Gate and Pulldown Claw 29
2.5 Flange Focal Distance Adjustment 29
Concept 29
Polishing a Spacer 30
Changing the Spacer 30
Adjusting the Viewing Screen 30
Flange Focal Distances 30
2.6 Magazine 31
Installing the Magazine 31
Removing the Magazine 32
2.7 Power 33
3
TABLE OF CONTENTS
