prod camera. The preferred method is by means of the OriginCplus,
which inputs timecode in ASCII form. It is also possible for the camera
to receive information in SMPTE form directly from a SMPTE timeco-
de device such as an TC audio recorder. Both methods are detailed be-
low.
7.4.1 Using the OriginCplus - Recommended Method• • Pro-
gram the OriginCplus by inputting Prod ID, accurate date and time
of day. Press the # key to scroll through each field; after all fields are
set as desired, Press * to start the clock.
• Make sure the camera has a battery attached.
• Plug the Lemo5 cable of the OriginCplus into Lemo5 chassis
mount on the base of the camera. On the XTRprod, the Lemo5
connector is located on the motor side to the lower left of the mo-
tor.
• Press * on the OriginCplus to send the timecode information. The
OriginCplus will display Good 00.0 after the timecode has been ac-
cepted by the camera. Likewise, the small yellow diode on the came-
98
