SPECIFICATIONS Page 2
SAFETY INSTRUCTIONS Page 3
REAR PANEL FUNCTIONS Page 4
MENU FUNCTIONS Page 7
FRONT PANEL FUNCTIONS Page 8
REMOTE FUNCTIONS Page 11
Contents:
Caution:
Specifications:
CAUTION: To reduce the risk of electric shock, do not remove cover
(or back). No user serviceable parts inside. Refer servicing to qualified
service personnel.
WARNING: To reduce the risk of fire or electric shock, do not expose
the amplifier to rain or moisture.
The lightning flash with an arrowhead symbol within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated ‘dangerous voltage’ within the
product’s enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.
Output:
2×300W/8 Ohm, 2×600W/4 Ohm
Distortion: <0.05% (THD+N: 1-100W / 8 Ohm)
IMD <0.008%
TIM <0.002% (10W 8 ohm)
Phono:
Floating RCA (1 set)
Load-impedance adjustable from 50 Ohm to 10 kOhm
Frequency response: +/-0.5dB (20Hz-20kHz)
Signal/noise >90dB @ 2V out
Distortion <0.02% (20Hz-20kHz)
RIAA correction curve
Gain: 71-81dB
Line:
Input impedance: 10 kOhm
Gain adjustable in 2dB steps
Gain line 1 and line 2: 5-15dB
Gain line 3: 1-11dB
Digital:
2 x BNC S/P-DIF (32-192kHz, 16-24 bit)
2 x TOSLINK optical (32-96 kHz, 16-24 bit)
1 x USB fully isolated, UAC 2, asynchronous (PCM 32-192kHz, 16-24 bit and
DSD64/DSD128)
Volume control:
Volume adjustable from -80dB to 0dB in 1dB steps
Dimensions:
95 x 440 x 410mm
Weight:
15.2kg
▲
▲▲▲▲▲
▲▲▲▲
▲▲▲
▲
▲▲
U-150 Integrated Amplifier User’s guide
