SPECIFICATIONS Page 2
SAFETY INSTRUCTIONS Page 3
REAR PANEL FUNCTIONS Page 4
FRONT PANEL FUNCTIONS Page 6
REMOTE FUNCTIONS Page 7
Contents:
Caution:
Specifications:
U-300 Unity Amplifier User’s guide
CAUTION: To reduce the risk of electric shock, do not remove cover
(or back). No user serviceable parts inside. Refer servicing to qualified
service personnel.
WARNING: To reduce the risk of fire or electric shock, do not expose
this apparatus to rain or moisture.
The lightning flash with an arrowhead symbol within an equi-
lateral triangle, is intended to alert the user to the presence of
uninsulated ‘dangerous voltage’ within the product’s enclosure
that may be of sucient magnitude to constitute a risk of
electric shock to persons.
Output: 2 x 300 W/8 Ohm, 2 x 600 W/4 Ohm
Distortion: <0.005% (THD+N: 1-100 W / 8 Ohm)
IMD<0.0008%
TIM<0.002% (10W 8-ohm)
Phono: Floating RCA (1 set)
Load-impedance adjustable from 50 Ohm to 10 kOhm;
Frequency response: +/-0.5dB (20 Hz-20 kHz)
Noise < -100dB re @ 2V out
Distortion < 0.01% (20-20 kHz)
RIAA correction curve
Gain: 62 dB
Line: Line 1. line 2, line 3: input impedance: 10 kOhm
Gain setting adjustable in 3 steps (3, 6, 12 dB)
Digital inputs adjustable in 2 steps 0-6 dB
Digital: 2 x RCA SPDIF (32 – 192 k-samples, 16-24 bit)
2 x TOSLINK optical (32 – 96 k-samples, 16-24 bit)
1 x USB fully isolated, UAC 2, asynchronous (PCM 32 – 192 k-samples, 16-24 bit)
Volume control: Volume adjustable from -80dB to 0dB in 80 1dB steps
Dimensions: 100 x 440 x 370 mm
Weight: 16.5 kg
▲
▲
▲
▲
▲ ▲
▲ ▲
▲ ▲
▲
