20 Chapter 3 Installation and wiring Manual Corrigo Ventilation, revision R

Description E tool
©
Display
Recirculation damper Recirculation Air Damper Recirc. damper
Heating 3-position actuator, increase Heating Increase Heat-inc
Heating 3-position actuator, decrease Heating Decrease Heat-dec
Exchanger 3-position actuator, increase
Exchanger Increase
Exch-inc
Exchanger 3-position actuator, decrease Exchanger Decrease Exch-dec
Cooling 3-position actuator, increase Cooling Increase Cool-inc
Cooling 3-position actuator, decrease Cooling Decrease Cool-dec
Step controller heating, step 1 Heat Step 1 Heat step1
Step controller heating, step 2
Heat Step 2
Heat step2
Step controller heating, step 3 Heat Step 3 Heat step3
Step controller heating, step 4 Heat Step 4 Heat step4
Step controller cooling, step 1 Cool Step 1 Cool step1
Step controller cooling, step 2 Cool Step 2 Cool step2
Step controller cooling, step 3
Cool Step 3
Cool step3
Extra time channel 1 Time Channel 1 Timer 1
Extra time channel 2 Time Channel 2 Timer 2
Extra time channel 3 Time Channel 3 Timer 3
Extra time channel 4 Time Channel 4 Timer 4
Extra time channel 5
Time Channel 5
Timer 5
Humidity Humidity/DeHumidity Humidity
External controller active Extra unit active ExtraUnitActi
Heating/cooling step 1 Heat/cool step 1 HeatCoolStep1
Heating/cooling step 2 Heat/cool step 2 HeatCoolStep2
Heating/cooling step 3
Heat/cool step 3
HeatCoolStep3
Free cooling operation Free cool run Free cool run
Pretreatment Pretreatment Pretreatment
Free cooling operation Free cool run Free cool run
Pretreatment Pretreatment Pretreatment
Split sequence active
Split Sequence
Split sequence
Run indication Run indication Run ind.
Pulse modulated heating output Heating PWM Heating PWM
