17.3 Control function
Control function
Mode:
Supply air control
There are eight different control functions to choose from:
1. Supply air control.
2. Outdoor-temperature compensated supply air control.
3. Cascaded room temperature control
4. Cascade connected extract air temperature control.
5. Outdoor temperature dependent switching between outdoor compensated supply air
temperature control and room temperature control
6. Outdoor-temperature controlled switching between Outdoor-temperature compensated
supply air control and Cascade connected extract air temperature control.
7. Outdoor compensated room temperature control
8. Outdoor compensated extract air control
For detailed description of the control modes, see section 5.1.1 Control modes.
In control modes five and six, there is a submenu for setting of the change-over outdoor
temperature.
Outdoor temp for
control mode change
13°C
17.4 Fan control
Fan control
1-speed
Choose between "Single-speed", "Two-speed", "Pressure control", "Flow control", "Frequency
manual" (fixed output), "Frequency external control", "SAF with EAF slave", or "SAF with EAF
flow control".
For detailed description of fan control alternatives, see section 5.4 Fan control.
Flow control
If flow control has been configured, there is a submenu for setting of calculation parameters for
conversion of pressure to flow. There are two menus, one for "SAF" and one for "EAF".
SAF flow control
factors
K-constant: 100
X-constant: 0.50
For more detailed description, see the section Air flow control under 5.4.1 Pressure control.
