Manual Corrigo Ventilation, revision R Chapter 10 Temperature 57
Chapter 10 Temperature
Here you can view all actual and setpoint values for temperature control. The menu is visible to all
users, regardless of log on level. However, to make changes you need at least Operator authority.
The below menus are available, providing the corresponding input has been activated.
Setpoints are available with a separate value for reduced speed. This is achieved using a temperature
offset when the unit runs in reduced speed.
The temperature is available in either Celsius (°C) or Fahrenheit (°F).
Setpoint.
Control mode 1: Supply air control.
Outdoortemp.:18.4°C
Supply air temp
Act.: 19.8°C Setp
Setp.: 20.0°C
Submenu: Setpoint
Supply air temp
Setp.: 20.0°C
Control mode 2: Outdoor compensated supply air control.
Control mode 5: Outdoor temperature dependent supply air or room temperature
control.
Control mode 6: Outdoor temperature dependent supply air or extract air control.
Outdoortemp.:18.4°C
Supply air temp
Act.: 19.8°C Setp
Setp.: 20.0°C
Submenu: "Setpoint curve"
In control modes five and six, the setpoint relationship is used when supply air control is
active.
Use the eight breakpoints to generate a "setpoint"/"outdoor temperature" relationship.
Both the outdoor and supply air temperatures are changeable for the curve.
Outdoor comp. setp.
-20.0°C = 25.0°C
-15.0°C = 24.0°C
-10.0°C = 23.0°C
Outdoor comp. setp.
-5.0°C = 23.0°C
0.0°C = 22.0°C
5.0°C = 20.0°C
To Next Page
