84 Chapter 17 Configuration Manual Corrigo Ventilation, revision R
17.6 Extra sequence Y4
"Extra sequence Y4" can be configured to one of the following alternatives: "Active", "Active with
cooling recovery", "Active with enthalpy control" and "Active with both cooling recovery and
enthalpy control".
Mode Extra Seq-
uence Y4
Not active
17.7 Extra sequence Y5
"Extra sequence Y5" can be configured to “Active” or “Not active”.
Mode Extra Seq-
uence Y5
Not active
17.8 Heating coil
Heating
water
The heater can be set to "Water", "Electric", "Water/Electric" or "Not used".
For detailed description of heater alternatives, see section 5.1.2 Heater types.
17.9 Exchanger
Exchanger
Rot. Exch
The heat exchanger unit can be set to one of the following alternatives:
• Plate exchanger
• Rotating exchanger
• Liquid connected exchanger
• Mixing dampers
• Not connected
• Damper limiting for minimum outdoor air percentage is settable 0…100%.
In the submenu parameters for outdoor temperature control of exchanger can be set.
Outd. temp control of
exch: Off
Outd. temp start: 10°C
Diff. stop: 0.2°C
For detailed description of exchanger alternatives, see section 5.1.3 Heat exchanger.
