ABB 07CR41 User Manual

Technical specifications 3 – 14 Advant Controller AC 31 / Issued: 01.99
3
3.5 Digital central extensions
3.5.1 View (see Figures 5, 6, 7 on the next page)
1 – Location for the DIN rail
2 – Plate fixture with unit earthing, alternative to 1
3 – release lever for DIN rail mounting
4 – Location for external dual connector
5 – Connectors for input/output cabling, under cover flap
6 – Status LEDs for inputs/outputs
7 – Connector for additional input/output extensions
8 – Connection to basic unit/remote unit or to the last input/output extension connected to
the basic/remote unit

ABB 07CR41 Specifications

General

Manufacturer	ABB
Model	07CR41
Product ID	07CR41
Extended Type Designation	07CR41
Country of Origin	Germany
Contact Configuration	4PDT
Mounting Type	DIN Rail
Terminal Type	Screw
Type	Relay Controller
