ABB UPS PRODUCTS AND SOLUTIONS
—
10
—
10 External battery
module rear view
—
Table 3: External battery module rear
panel connectors and ports
13 EBM terminal
14 Fuse board cover (to replace EBM fuse)
15 EBM connector
