ACH580 E-Clipse bypass and packaged drive user manual 103
Embedded fieldbus
• Change of State (COS) enabled
• Warning Enabled
• Warning Enabled
• Override value is received, but there is no action taken.
Binary Input – The binary input objects support the following features:
• Binary Input actual value
• Normal / Warning state specification
• Warning Enabled
• Change of State (COS) enabled
• Override value is received, but there is no action taken.
Analog Output – The analog output objects support the following features:
• Analog Output value in engineering units
• Override value is used to change the Analog Output value. It is not possible to
return to the previous value by removing the override. The override feature is
used only to change the value.
Binary Output – The binary output objects support the following features:
• Binary Output value
• Override value is used to change the Binary Output value. It is not possible to
return to the previous value by removing the override. The override feature is
used only to change the value.
N2 analog input objects – Drive
The following table lists the N2 Analog Input objects defined for the ACH580 drive.
N2 Analog Inputs:
Number Object
Drive
Parameter
Resolution Units Range
AI1 OUTPUT FREQUENCY 01.06 0.1 Hz 0…250
AI2 RATED SPEED 01.62 0.1 % 0…100
AI3 SPEED 01.01 1 rpm 0…9999
AI4 CURRENT 01.07 0.1 A 0…9999
AI5 TORQUE 01.10 0.1 % -200…200
AI6 POWER 01.17 0.1 kW 0…65535
AI7 DRIVE TEMPERATURE 05.11 0.1
% -40…160
AI8 KILOWATT HOURS 01.58 1 kWh 0…65535
AI9 MEGAWATT HOURS Derived value 1 MWh 0…65535
AI10 RUN TIME 05.03 1 H 0…65535
AI11 DC BUS VOLTAGE 01.11 1 V 0…999
AI12 OUTPUT VOLTAGE 01.13 1 V 0…999
AI13 PRC PID FEEDBACK 40.97 0.1 % 0…100
