Embedded fieldbus
BV10 RUN/STOP CMD This object commands a drive
start. Control requires bypass
parameter 1601 value = comm.
RUN/STOP C
BV11 FWD/REV CMD This object commands a motor
rotation direction change.
Control requires 20.11 =
request (0) and drive configured
to receive the reference over
the fieldbus.
REV/FWD C
BV12 RUN
PERMISSIVE
CMD
This object commands Run
Permissive. Control requires
parameter 1601 value = COMM.
ENABLE/
DISABLE
C
BV13 EXT 1/2 CMD This object selects EXT1 or
EXT2 as the active control
source. Control requires
parameter 19.11 value = EFB
MCW bit 11 (32).
EXT2/EXT1 C
BV14 FAULT RESET This object resets a faulted
drive. The command is
rising-edge triggered.
RESET/NO C
BV15 MBOX READ This object reads a parameter
(defined by AV25 MBOX
PARAM) and returns it in AV26
MBOX DATA.
READ/RESET W
BV16 MBOX WRITE This object writes the data value
specified by AV26, MBOX
DATA, to a parameter (defined
by AV25, MBOX PARAM).
WRITE/RESET W
BV17 LOCK PANEL This object locks the panel and
prevents parameter changes.
The corresponding drive
parameter is 96.02.
LOCK/UNLOCK W
BV18 CTL OVERRIDE
CMD
This object commands the drive
into BACnet Control Override.
In this mode, BACnet takes
drive control from the normal
source. However, the control
panel’s HAND mode has priority
over BACnet Control Override.
ON/OFF C
BV19 CTL OVERRIDE
ACT
This object indicates whether
the drive is in BACnet Control
Override. (See BV18.)
ON/OFF R
BV20 START
INTERLOCK 1
This object commands start
interlock1. Control requires
bypass parameter 1603 value =
COMM.
ENABLE/
DISABLE
C
BV21 START
INTERLOCK 2
This object commands start
interlock1. Control requires
bypass parameter 1604 value =
COMM.
ENABLE/
DISABLE
C
BV24 STARTED MON This object indicates the drive’s
started status.
START/NO
START
R
Instance
ID
Object Name Description
Active/Inactive
Text
Present Value
Access Type
