ACH580 E-Clipse bypass and packaged drive user manual 131
Embedded fieldbus
AV31 SPD OUT PCT This object indicates the drive’s output
speed, as a percentage of rated.
Percent R
AV32 CUR OUT PCT This object indicates the drive’s output
current, as a percentage of rated.
Percent R
AV33 MAX
CURRENT
This object indicates the drive’s
maximum output current.
Percent R
AV40 PRC PID FBK
RD
This object indicates the drive’s process
PID feedback.
Percent R
AV41 PRC PID STPT
RD
This object indicates the drive’s process
PID setpoint.
Percent R
AV42 PRC PID STPT
WR
This object sets the drive’s process PID
setpoint.
Percent C
AV43 PRC PID FBK
WR
This object sets the drive’s process PID
feedback.
Percent C
AV44 PRC PID OUT This object indicates the drive’s process
PID output.
Percent R
AV45 PID SET1 GAIN This object sets the drive’s process PID
set1 proportional gain.
None W
AV46 PID SET1
ITIME
This object sets the drive’s process PID
set1 integration time.
Seconds W
AV49 PRC PID DEV
MON
This object indicates the drive’s process
PID deviation.
Percent R
AV53 PID SET2 GAIN This object sets the drive’s process PID
set2 proportional gain.
None W
AV54 PID SET2
ITIME
This object sets the drive’s process PID
set2 integration time.
Seconds W
AV55 EXT PID FBK
RD
This object indicates the drive’s external
PID feedback.
Percent R
AV56 EXT PID STPT
RD
This object indicates the drive’s external
PID setpoint.
Percent R
AV59 EXT PID OUT This object indicates the drive’s external
PID output.
Percent R
AV60 EXT PID
PGAIN
This object sets the drive’s external PID
proportional gain.
None W
AV61 EXT PID ITIME This object sets the drive’s external PID
integration time.
Seconds W
AV64 EXT PID DEV
MON
This object indicates the drive’s external
PID deviation.
Percent R
AV130 KWH CUR HR This object indicates the drive’s energy
usage for the current hour.
kWh R
AV131 KWH PRV HR This object indicates the drive’s energy
usage for the previous hour.
kWh R
AV132 KWH CUR DAY This object indicates the drive’s energy
usage for the current day.
kWh R
AV133 KWH PRV DAY This object indicates the drive’s energy
usage for the previous day.
kWh R
Instance
ID
Object Name Description Units
Present Value
Access Type
