ABB ACS2000 AFE 2MVA - Replacing Phase Modules

CHAPTER 10 – PREVENTIVE AND CORRECTIVE MAINTENANCE 174
10.6.12 Replacing a phase module
Phase modules location
Dimensions and weight
—
References
—
10-14 Phase modules
location
—
10-15 Phase module –
Dimensions and weight
—
10-14
INU phase module 1
INU phase module 2
INU phase module 3
AFE phase module 1
AFE phase module 2
AFE phase module 3
—
10-15
W (width) L (length) H (height) Weight
900 mm 650 mm 250 mm 63 kg
L
H
W
